| GENERAL | PROPULSION SYSTEM |
|---|---|
| IMO: 9770842 Length overall: 28.67 m Beam overall: 10.43 m Depth at sides: 4.60 m Draught aft: 4.72 m Displacement: 531 T Gross tonage: 294 T |
Main Engine: 2 x Caterpillar 3516C TA HD/C Total Power: 3730 kW (5000 Hp) at 1600 rpm |
| DECK EQUIPMENT | NAUTICAL & COMMUNICATION EQUIPMENT |
|---|---|
| Tow Winch Forward: Double Drum, 35 T, 28m/min Tow Wires Fwd: 2 x 90m Corona Line Winchline PET3 80mm Towing Hook Aft: Mampaey 65 T Deck Crane: Heila HLM 20-3S 1.7T @ 10.56m Winch Capacity Deck Crane: 2.1 T Push Bow: Rubber Bow Fender and Cylindrical Bow Fender FiFi Set: 2500 m³/hr FiFi monitor: 2x 1200 m³/h, water/foam, 10 bar |
GMDSS: Furuno FS-1575 Radar: Furuno FAR 2117 VHF Radio Telephone: S.P. Radio, type Sailor Compact 6222 Handheld: Jotron Tron TR-20 Navtex: Furuno NX-700 Elec. Chart System: Furuno FMD-3100 Autopilot: Simrad AP-70 Echo Sounder: Furuno LS-6100 GPS: Furuno GP-150 Sat compass: Furuno SC-50 AIS: Furuno FA-150 Magnetic Compass: Cassens & Plath, Type Kotter |
| CAPACITIES | AUXILIARY EQUIPMENT |
|---|---|
| Fuel oil: 72.00 m³ Fresh water: 14.9 m³ Lubrication Oil: 9.00 m³ Dirty Oil: 3.10 m³ Bilge water: 5.10 m³ Sewage: 2.20 m³ Foam: 6.5 m³ Dispersant: 4.7 m³ |
Main Generator Sets: 2 x Caterpillar C4.4 TA Capacity: 2 x 107 kVA, 50Hz, 230/400 V |
| PERFORMANCE | ACCOMMODATION |
|---|---|
| Speed approx.: 13 knots Bollard Pull: 61 Tbp |
Accommodation: 7 3x single cabins, 2x double cabins |
