Sora 5
A rapid, 21-knot Light Utility and Pilot Vessel built with a robust aluminum hull. Perfectly suited for demanding crew transfer and active pilot duties with seating for 12 personnel.
Built2012
Speed21 Knots
Capacity12 Seats / 2 Crew
Technical Specifications
General
Hull MaterialAluminum
Build2012
SuperstructureFRP
Basic FunctionsCrew and Pilot duties
ClassificationBureau Veritas
NotationI ✠ Hull • MACH
TypeLight Ship / Fast Utility Vessel
Sea Area2
Dimensions
LOA13.72 m
Breadth (B)3.76 m
Draft (T)1.07 m
Displacement18 tonnes
Performances
Speed21 knots
Range150 nm at max speed
Capacities
Fuel Oil0.87 m³
Fresh Water0.08 m³
Sewage0.03 m³
Max. Deck Load0.50 t
Crew2 persons
Propulsion system
Main Engines2 × Caterpillar TA
3208
(2 × 315 BHP)
(2 × 315 BHP)
Auxiliary Power1 × Cummins Onan MDKDP
(13.5 kVA)
Propulsion2 × FPP
Max Speed12 knots
FO Capacity1100 liters
FW Capacity200 liters
Range150 nm
Auxiliary Equipment
Engine Room Ventilation2 × 1500
m³/h
General Service PumpsElectrically driven,
24V, Azcue CA 40
Cathodic ProtectionInstalled
Deck layout
Anchor Equipment1 × 20 kg HHP with
chain and line
Fendering230 mm × 115 mm
D‑shaped foam filled fender
Life Saving Equipment
Life Buoys2
Life JacketsBased on persons onboard
Life Rafts1 × 16 persons
Accommodation
Below Main DeckPantry, toilet & 2
bunks
Main Deck12 Seats
Air-conditioning24,000 BTU
Electrical Equipment
Electrical Network24V d.c.; 230V 50
Hz
Generator Set1 × Onan 4.0
MDKBM
Capacity4.0 kW, 5.0 kVA
Nautical, Surveillance & Communication Equipment
Searchlight1 × 250W 24V
CompassMagnetic
Echo SounderInstalled
RadarInstalled
